Model and mold making paste,manually mixed and applied epoxy resin paste
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Type: | Epoxy Paste,Tooling Paste, Epoxy Resin Paste | Density: | 0.7-0.8 G/cm3 |
|---|---|---|---|
| Color: | Brown,White | Chemical Resistance: | Strong |
| Suitable Surfaces: | Wood, Metal, Ceramic, Stone | Handling Way: | Manually Mixed |
ZK5200A/B Model and mold making paste,manually mixed and applied epoxy resin paste, is two-component epoxy-based materials,very easily shaped and CNC machined,used for model and mold of UAV(short for Unmanned Aerial Vehicle).
Dongguan ZEEK New Materials Co., Ltd is professional supplier of customized model and mold making paste from CHINA.
Model: ZK-tool®5200A/B
| Material | 5200A | 5200B | Mixed |
| Description | epoxy resin | curing agent | |
| mixing ration | 1 | 1 | |
| Color: | brown | white | brown |
| mixed time:500g,25°(min) | 30 | ||
| curing time before machining(20-25mm) (hours) | 6-8 | ||
| layer thickness (mm) | max.40 | ||
| Density:(g/cm³): | 0.7-0.8 | ||
| Hardness(Shore D): | 65-70 | ||
| Temperature Resistance(°C): | 70-75 | ||
| Coefficient of Thermal Expansion(10-6 K-1): | 45-50 | ||
| Compressive Strength(N/mm²): | 16.2 | ||
| Flexural Strength(N/mm²): | 19.2 | ||
| Tensile Strength(N/mm²): | 12.4 | ||
| Package(kg) | 10 | 10 |
Characteristics: can be mixed and applied without the need for specialist equipment,very easily shaped and machined,excellent dimension stability.
Applications:benchmark model, yacht model,system and sand-cast model, rapid prototype,car model,UAV model,etc
